CB radio station kit PNI Escort HP 5500 and CB antenna PNI Extra 48, 45 cm, SWR 1.0, with magnet included

PNI-HP5500 - CB radio station PNI Escort HP 5500, multistandard, 4W, AM-FM, 12V/24V, ASQ, RF Gain, cigarette lighter socket includedProduct identificationManufacturer PNIProduct code PNI-HP5500Product type CB radio stationGeneral characteristicsModel MobileType of AM / FM emission bandChannels 40Frequency 26.965 - 27.405 MHzMicrophone type (pins) 6 pinsSpeaker audio power 3 WSensitivity (20dB SINAD) FM -120 dBm, AM -118 dBm@ SINAD 12dBAudio signal distortion less than 5% @ 1KHzEmission power 4 WFM modulation: 2 KHz, AM: 80%EEPROM memory YesPower supply 12 V / 24 VDimensions (L x H x A / Weight) 115 X 115 X 35 mm / 611 grSpecial featuresRF Gain YesASQ Yes, 5 levelsADJUSTABLE ASQ YesEmergency channels YesDigital automatic squelch (ASQ) YesManual squelch YesAccessory connection 1 pin socketOperating temperature -26°C ~ +80°CScreen illuminationLCD display typeRear panel connectionsAdditional speaker connection YesPackage containsRadio station YesMicrophone YesRadio station mounting bracket and screws YesMicrophone mounting bracket and screws YesPower cable YesCigarette lighter socket YesUser manual YesPNI-EXTRA48 - PNI Extra 48 CB antenna, with magnet included, 45 cm, 26-30MHz, 150W, SWR 1.0, fiberglassProduct identificationProduct code PNI-EXTRA48CB working bandProduct color (spike) BlackGeneral featuresWorking frequency 26 - 30 MHzMaximum applied power 150WMinimum S.W.R. in the center of the band 1.0Length 45 cm (magnetic base included) Spike length: 44 cmImpedance 50 OhmMaterial FiberglassConnector type PLCable length 4mWeight 193 gDimensions 450 x 103 x 66 mmGain >5 dBiPolarization VerticalWorking distance 10 kmMagnetic base 103 x 66 x 40 mmOperating temperature -26°C ~ +80°CPackage containsRadio station antenna YesRG174 cable Yes, 4 mPL259 plug Yes

• The PNI Escort HP 5500 has been designed with simplicity in mind so that everyone can use it without any problems. The high-quality electret capacitor encapsulated in the microphone ensures a clear and powerful sound.
• The CB radio transmitter PNI Escort HP 5500 allows the most accurate control over the background noise specific to the CB band. The analog potentiometer adjustable SQ function and 5-stage ASQ allow the user to filter and remove noise, making communication clearer. The 7-stage RF gain function allows control over the reception frequency and reduces distortion.
• By adjusting the frequency and modulation, you can use the transmitter in the UK and most countries of the European Union. The PNI Escort HP 5500 is equipped with the most important European bands.
• How to change the frequency band: 1. Turn off the transmitter. Press the PTT button + the UP button on the microphone at the same time while restarting the radio station 2. The LED corresponding to the A/F button lights up and the current standard appears on the screen. 3. Press the UP DOWN buttons to reach the desired rate, and then restart the transmitter or press the PTT button to exit the rate setting mode.
• + CB antenna PNI Extra 48
