Curved Bottle Screen Printing Machine, Manual Cylinder Printing Machine, Curved Screen Printing Machine Cylindrical Products with Diameter Less Than 80mm

Name: Cylinder screen printerMaterial: SteelProduct structure: Front and rear push-pull typeMaximum image area: 160*140MMApplicable screen: Outer diameter 300*250MMMaximum screen thickness: 30MMMaximum diameter of cylinder/cone: 80MMWeight of screen printer: 17KGProducts include:1*Curved screen printer

• Curved screen printer: The curved screen printer is suitable for printing cylindrical and conical products with a diameter of less than 80mm. The maximum printing height of the printer is 140mm. It is easy to use and has high working efficiency.
• Screen size: The curved screen printer is suitable for printing cylindrical and conical products with a diameter of less than 80mm. The screen frame size is 300 x 250mm and the maximum printing area is 160 x 140mm.
• Rollers: Three sets of rollers are used to place the substrates, namely metal bearing rollers (diameter 19mm); nylon bearing rollers (diameter 25mm); plastic bearing rollers (diameter 50mm), which can be replaced by users as needed. Three rollers can be installed on both the main frame and the sub-frame.
• Humanized design: The humanized handle design makes the entire printing process convenient and safe. The small storage board provides you with more storage space.
• Various applications: The screen printing unit is designed for various cylindrical and conical products, such as bottles, small cylindrical cups, cosmetic bottles, mugs, thermos cups, etc.
