DIN Rail & Top Flange, Enclosed Power Relay, 30 A, 4 Pins, Screw 725AXXSC3ML-120A
Product details
| Management number | 238178888 | Release Date | 2026/07/11 | List Price | US$16.94 | Model Number | 238178888 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Enclosed Power Relay, Coil Voltage 120V AC, Contact Form SPST-NO, Current Rating 30 A, Electrical Connection Screw Terminal, Number of Pins 4, Status Indicator LED Indicator, Contact Rating (AC) 30 A @ 240/277V, Contact Rating (DC) 30 A @ 28/30V, Horsepower @ 120V AC 1 1/2 hp, Horsepower @ 240V AC 3 hp, Mounting Style DIN Rail & Top Flange, Push-To-Test Method Test Button, Body Depth 1.3 in, Body Height 1.3 in, Body Width 2.67 in, Coil Resistance 5,200 ohm, Contact Material Silver Alloy
- 3hp @ 277V AC, LED & Button
- Standards CE Certified, CSA Certified, IEC
- Base Type DIN, Flange
- Depth 2.12 in (53.9 mm)
- Electrical Connection Screw
- Height 2.67 in (67.7 mm)
- Length 12.500
- Series Harmony(TM) 725 Power Series
- Width 1.37 in (34.9 mm)
| Amps | 30 Amps |
|---|---|
| Brand | Schneider Electric |
| Size | 1.3" x 1.3" x 2.67" |
| Assembled product weight | 2.55 lb |
| Has nrtl listing certification | N |
| Has written warranty | No |
| Model | 725AXXSC3ML-120A |
| Multipack quantity | 1 |
