ZAPCO Z-2KD II Mono Class D Sound Q Amplifier

The ZAPCO Z-2KD II Mono Class D Sound Q Amplifier is a powerful and versatile audio solution designed for audiophiles and car audio enthusiasts. With a maximum power output of 2100 watts at 1 ohm, this amplifier delivers exceptional performance and stability, thanks to its PWM MOSFET power supply and advanced features like variable low-pass crossover, bass boost equalization, and phase shift control. Its compact design and selectable master/slave operation make it easy to integrate into a variety of audio systems, providing a seamless and immersive listening experience.

• This mono class D linkable bass amplifier is designed for powerful and efficient performance.
• It is stable into 1 Ohm and can be linked/strapped with a second amplifier to achieve 2 Ohm operation.
• The amplifier features a PWM MOSFET power supply for reliable and consistent power delivery.
• It has a 24 dB variable low pass (LPF) crossover to customize the frequency response.
• The 12 dB variable bass boost equalization allows you to tailor the low-end performance.
• The 0-180 degree variable phase shift provides flexibility in tuning the system.
• The 24 dB variable subsonic filter helps to eliminate unwanted low-frequency content.
• The selectable master and slave operation enables linked (strapped) amplifier configuration.
• The amplifier delivers 800 watts of power at 4 Ohms, 1400 watts at 2 Ohms, and 2100 watts at 1 Ohm.
• When linked/strapped, the amplifier can achieve 3600 watts of power at 2 Ohms.
• The THD at rated power is less than 0.05%, ensuring clean and distortion-free audio.
• The signal-to-noise ratio is greater than 90dB, providing a quiet and dynamic performance.
• The damping factor is over 350, providing excellent control over the connected speakers.
• The amplifier has an efficiency of 86%, making it an energy-efficient choice.
• The input sensitivity range is 0.2v to 8v, allowing compatibility with a wide range of source devices.
• The net dimensions of the amplifier are 190(W) x 62(H) x 450(L) mm, and the overall dimensions are 190(W) x 62(H) x 486(L) mm.
